Huawei AR550C-4GE Agile Gateway Router (AR550 Series)

Networking & Software Features

• Wired Transfer Rate: 10/100/1000 Mbps (Gigabit Ethernet)

• Max. LAN Data Rate: 1000 Mbps

• Modem Function: Yes

• VPN Support: Yes

• Private Mold: No

LAN Functions

• VLAN Support: IEEE 802.1P, IEEE 802.1Q, and IEEE 802.3

• MAC Address Management: Static MAC address, dynamic MAC address, MAC address learning restriction, MAC address flapping prevention.

• Other Protocols:

  • Port Aggregation and LACP (Link Aggregation Control Protocol)

  • LLDP (Link Layer Discovery Protocol)



    Processor	Dual-core, 700 MHz
    Fixed Ethernet interfaces	2 x 2.5G SFP(Compatible with GE), 4 x GE RJ45
    Alarm Relay interface	1 DI 1 DO (terminal block, support Normal Open and Normal Closed)
    Layer 2 forwarding performance	Up to 13.5 Mpps
    Switching capacity	Up to 128Gbps
    DRAM memory	256 MB
    Flash memory	512 MB
    LAN functions	IEEE 802.1P, IEEE 802.1Q, and IEEE 802.3 VLAN Static MAC address, dynamic MAC address, MACaddress learning restriction, MAC address flapping prevention Port aggregation and LACP LLDP

Ordering & Payment Terms:

• Minimum Order Quantity (MOQ): Flexible for small orders
• Shipping: DDP (Delivered Duty Paid) to your destination or shipment via your designated courier account.
• Payment Method: T/T (Bank Transfer)
• Payment Terms:
  30% advance payment, with 70% balance due prior to shipment for bulk orders

BANK INFORMATION

Bank Name: DBS BANK (HONG KONG) LIMITED
Account Name: Shenzhen VAN Electronics Co., Ltd.
Account No.: 798 291 1671
Bank Address: 11th Floor, The Center, 99 Queen's Road Central, Central, Hong Kong
Swift Code: DHBKHKHH

Contact for Quotation:
Kindly email your requirements to sales@szvan.com for a customized quotation and optimal solution.
Attn: Jessica Lee
